【FEATURES】
- Compact, lightweight and rugged construction.
- Easy operation, even for unskilled personnel.
- Full marine-use VHF channels.
- Designed to meet GMDSS requirements related to performance standards for survival craft two-way VHF radiotelephone apparatus,
such as IMO MSC.515(105) and IEC 61097-12.
- CCS type approval.
- DNV type approval.
- RS type approval.
- VR type approval.
【SPECIFICATIONS】
| Technical Specifications | |
| Frequency Range: | 156.025～157.425 MHz (TX) 156.050～162.000 MHz (RX) |
| Operating Channels: | 19 channels (default) |
| Operating Hours: | ≥8 hours ( TX10%, RX10%, Standby80% ) |
| Output Power: | High 3.0W / Low 0.5w |
| Battery Requirements | |
| Battery Voltage: | DC 9V (NBT200), DC 7.2 V (NBT200C) |
| Storage Time: | max 4 years on board (see Note 1) |
| Storage Temp. | -40℃～+70℃ |
| Dimension & Weight | |
| Dimension: | 256(H) × 51.4(W) × 46.2(D) mm |
| Weight: | 200g (Transceiver+Antenna+Emergency Battery) |
*Note1: It is recommended that the battery can be stored at the dealer/agent max 1 year since purchased and it should be replaced in 4 years after supplied to a vessel.
NSR NTW-1000 TWO-WAY VHF RADIO BROCHURE.pdf
