【FEATURES】
- NSR’s own FFC and FPC adopted.
- Real monitoring software available for easy check.
- Flexible configuration for either VDR or S-VDR.
- Linux O/S used in firmware of VDR system.
- Large size color LCD with touch screen operation.
- Data interface to BAM System.
- NVR-9000S SVDR is designed to comply with the latest IMO regulation MSC.493 (104), IMO MSC.302 (87), IEC 62923-1, IEC 62923-2 and IEC 62288.
- Float-Free Capsule (FFC) or Fixed Protective Capsule (FPC) can be selected as the storage medium.
- Both FFC and FPC has the capacity of 64G each.
- Data Acquisition Unit (DAU) is fitted with LRU (64G SSD).
- 8 ch of serial ports are available in DAU.
- DNV type approval.
- CCS type approval.
- VR type approval.
- RS type approval.
【SPECIFICATIONS】
| Data Acquisition Unit (DAU) | ||
| Interface: | Ethernet IEC 61162-450 | 4 ch |
| Serial IEC 61162-1/2, RS422 | 8 ch | |
| VHF Audio | 2 ch | |
| Microphone | 8 ch | |
| Remote Alarm Unit | 1 ch | |
| USB | 1 ch | |
| DC 24V output: | Remote Alarm Unit (RAU) | 1 ch |
| Fixed Protective Capsul (FPC) | 1 ch | |
| Float-Free Capsule (FFC) | 1 ch | |
| LRU: | Memory | 64 GB |
| Recording Duration | min 48 hours | |
| Reserve Battery Capacity: | min 2 hours | |
| Fixed Protective Capsule (FPC) | Memory | 64 GB |
| Recording Duration | min 48 hours | |
| Beacon Battery Capacity | min 90 days | |
| Beacon Battery Life | 3 years | |
| Float-Free Capsule (FFC) | Memory | 64 GB |
| Recording Duration | min 48 hours | |
| Battery Capacity | min 168 hours | |
| Battery Life | 5 years | |
| Data Extension Unit (DEU) (OPTIONAL) | ||
| Interface: | Analog Input | 8 ch |
| Digital Input | 64 ch | |
| Serial IEC 61162-1/2 | 16 ch | |
| Ethernet | 1 ch | |
| Video Interface Unit (VIU) (OPTIONAL) | ||
| Interface: | VGA | 1-2 ch |
| Ethernet | 1-2 ch | |
| Remote Alarm Unit (RAU) | Serial IEC 61162-1/2, RS422 | 1 ch |
| POWER SUPPLY | Data Acquisition Unit (DAU) | AC110V/220V, 0.5～1.5A, |
| Data Extension Unit (DEU) | DC24V, 0.5A | |
| Video Interface Unit (VIU) | DC24V, 0.3A |
*For SVDR, FPC or FFC may be selected between.
NEB-2000C-VDR/NFP-2000C is supplied together with a Junction Box (NEB205) and cable (30m).
